RF METAL CO2 LASER TUBE

  • Idustrial C2 Lser Tubes
  • Medical co2 laser tubes
  • RECI CO2 LASER TUBE INDUSTRIAL USE z2 z4 z6 z8 w2 w4 w6 w8
  • RF METAL CO2 LASER TUBE
  • EFR CO2 LASER TUBE 1200CL 1600CL F2 F4 F6 F8 F10 ZN-1250 ZN-1450 ZN-1650 ZN-1850
  • YONGLI CO2 LASER TUBE 1230-1 1630-1 1230-G 1630-G 1650-B 1850-B 2000-B 1250-J 1400-J 1850-J HS-200W
  • handheld co2 laser power meter 200w
  • water cooling co2 laser power meter
  • laser protection goggles co2 yag fiber
  • SDZ CO2 LASER TUBE
  • chengdu co2 laser tube
  • 300W 400W CO2 LASER TUBE 200W CO2 LASER TUBE

Product Abstract:

Features:laser point model good , long life, stable and strong, can be refilled. Used for co2 laser engraving machine, cutting machine, marking machine.


Product Description

RF METAL CO2 LASER TUBE

Features:laser point model good , long life, stable and strong, can be refilled.
Used for co2 laser engraving machine, cutting machine, marking machine.



8W AIR COOL

Wavelength:

10.57-10.63um

Output Power:

8W

Power Stability

±5%

Mode Quality

:TEMoo

Beam Diameter

3.5mm

Beam Divergence

4mrad

Polarization:

:50:1(Vertical)

Frequency Modulation:

:0-20KHz

Input Voltage / Current

30VDC/14A

Cooling:

Air

External Dimensions:

70×100×340



25W AIR COOL

Wavelength:

10.57-10.63um

Output Power:

25W

Power Stability

±5%

Mode Quality

:TEMoo

Beam Diameter

3.5mm

Beam Divergence

4mrad

Polarization:

:50:1(Vertical)

Frequency Modulation:

:0-20KHz

Input Voltage / Current

30VDC/14A

Cooling:

Air

External Dimensions:

122×100×453



30W AIR

Wavelength:

10.57-10.63um

Output Power:

30W

Power Stability

±5%

Mode Quality

:TEMoo

Beam Diameter

3.5mm

Beam Divergence

4mrad

Polarization:

:50:1(Vertical)

Frequency Modulation:

:0-20KHz

Input Voltage / Current

30VDC/14A

Cooling:

Air

External Dimensions:

71×100×805



30W WATER COOL

Wavelength:

10.57-10.63um

Output Power:

8W

Power Stability

±5%

Mode Quality

TEMoo

Beam Diameter

3.5mm

Beam Divergence

4mrad

Polarization:

:50:1(Vertical)

Frequency Modulation:

:0-20KHz

Input Voltage / Current

30VDC/14A

Cooling:

water

External Dimensions:

71×100×833



50W WATER

Wavelength:

10.57-10.63um

Output Power:

50W

Power Stability

±5%

Mode Quality

TEMoo

Beam Diameter

3.5mm

Beam Divergence

4mrad

Polarization:

:50:1(Vertical)

Frequency Modulation:

:0-20KHz

Input Voltage / Current

30VDC/28A

Cooling:

Water

External Dimensions:

100×122×830



100W WATER

Wavelength:

10.2-10.7um

Output Power:

100W

Power Stability

±10%

Mode Quality

:TEMoo

Beam Diameter

2.3mm±0.4

Beam Divergence

<11mrad

Polarization:

 Linear reasonably

Frequency Modulation:

0-100KHz

Input Voltage / Current

50 rms,100 peak

Cooling:

WATER

External Dimensions:

780×190×180
