CO2 laser marking machine

  • CO2 laser marking machine
  • co2 laser marking machine and parts
  • co2 laser marking machine with rf metal tube
  • co2 laser marking machine with glass tube

Product Abstract:

CO2 laser marking machine 150*150mm 30w synrad, ezcad software,


Product Description

Performance indicators
The imported United States C02 lasers, high-speed scanning galvanometer, fast, high precision.

Software using WINDOWS interface, compatible with COREI-DRAW, AUTOCAD, PHOTOS Bu lOP and many other software outputed files.

Support PLT, PCX, DXF, BMP and other files, directly use SH ×, TTF font.

Support automatic coding, serial number, batch number, date, bar code and two-dimensional code marking.

Computer freely design graphics and text, flexible and convenient, without printing consumables. Processing costs is low.

Laser marking is non-toxic, non-distortion, no pollution, wear-resistant. Optional rotary table for marking circle products.

Advantages of products:

Laser: Selected original USA imported laser, the light is stable, low failure rate, life expectancy up to 45,000 hours, one-time investment

 high, use and maintenance costs low.

Domestic C02 glass tube can also be used, long warranty 6-10 months, low investment and quick refund.

Control computer: usage of industrial control computer (IPC), to ensure the industrial equipment can work long and stable in industrial

environments, and not easy to crash.

Control software: powerful function, with a graphical alignment, hierarchical to set parameters and red light position preview function.

 Graphic calculation accurate .Can mark a variety of bar code and graphics code, and have the reverse marking function.

Cooling system: air cooling, no need water or extra refrigerator.

Application:

1.Glasses industry: frames, lenses and other marking; 2.digital industry: IC marking, MP3, MP4, U disk, camera and other shell marking;

3.Digital Industry: bottom of the watch, watch decoration and other marking ; 4. plastic industry: the mobile phone key-press, cell phone case,

 charger, case, toys, etc.; 5.gifts: wood products, crystal, organic glass, leather carving and cutting; 6.leather clothing:

shoes, handbags and other carved, hollow, cutting; 7.The other industry: lighting, fabric carved, hollow and so on.

Parameters:



Laser parameters

-CO2-10W

-CO2-30W

-CO2-50W

-CO2-100W

Max laser power

10W

30W

50W

100W

Engraving depth

≤0.3mm

≤0.3mm

≤0.5mm

≤0.8mm

Minimum line width

0.1mm

0.1mm

0.15mm

0.15mm

Gross Power consumed

<1KW

<1.2KW

<2KW

<4KW

Laser wavelength

10.64um

10.64um

10.64um

10.64um

Laser repetition frequency

≤50KHz

≤50KHz

≤50KHz

≤50KHz

Marking scope

100mm×100mm

100mm×100mm

100mm×100mm

100mm×100mm

Optional engraving area

150mm×150mm

200mm×200mm

250mm×250mm

300mm×300mm

Engrave line speed

≤7000mm/s

≤7000mm/s

≤7000mm/s

≤7000mm/s

Minimum character

0.4mm

0.4mm

0.4mm

0.4mm

Repeat precision

±0.01mm

±0.01mm

±0.01mm

±0.01mm

Power requirements

220V±10%/50Hz

220V±10%/50Hz

220V±10%/50Hz

220V±10%/50Hz

System Dimension

(L * W * H) based on the actual model appearance and size.

Optical system size

1200mm×430mm×1200mm

Control system size

560mm×660mm×1000mm

Note: the whole machine is made up of optical path, control boxes, displays, work table. rotary table and automatic matching system are optional.
